SDLL60
| Overall Weight | 650t | Hydraulic Oil Tank Capacity | 11.5L |
| Engine Brand/Model | Rato R420 | Engine Oil Capacity | 1.1L |
| Rated Power | 8.5kw / 3600r/min | Overall Length | 2055mm |
| Bucket capacity | 0.13m³ | Overall Width | 1090mm |
| Bucket Width | 1000mm | Overall Height | 1270mm |
| Traveling Motor | Ruili / Litu | Body Width | 650mm |
| Travel Speed | 0-4km/h | Max. Operating Height | 2100mm |
| Hydraulic System | Gear Pump: Tianjin Xingzou / Multi-way Valve: Lixin | Max. Pin Height | 1800mm |
| Max. Lifting Capacity | 200kg | Max. Dump Height | 1480mm |
| Max. Gradeability | 25% | Ground Clearance | 110mm |
| Fuel Tank Capacity | 6.6L | Bucket Dump Angle | 30° |
|
OPTION ● Standard 〇 Optional — N/A |
ENGINE |
1. Briggs & Stratton 25T2 – Single-cylinder Gasoline (EPA/EURO5), 10kW/3600r/min 2. Koop 192 – Single-cylinder Diesel (EURO5), 7.6kW/3000r/min 3. Upower 192 – Single-cylinder Diesel (EURO5), 7.6kW/3000r/min |
| 〇Rubber (width * pitch * number of sections) | 150*72*34 | |
| 〇Steel (width * pitch * number of sections) | – | |
| Tires | – | |
| Cab | – | |
| Canopy | – | |
| Armrest | ● | |
| Tensioning Type | Mechanical Tensioning | |
| Air Conditioning (A/C) | – |
