SDLL3000
| Overall Weight | 1100t | Hydraulic Oil Tank Capacity | 25L |
| Engine Brand/Model | Rato R825 | Engine Oil Capacity | 1.6L |
| Rated Power | 20.5kw / 3600r/min | Overall Length | 2660mm |
| Bucket capacity | 0.18m³ | Overall Width | 910mm |
| Bucket Width | 900mm | Overall Height | 1810mm |
| Traveling Motor | Ruili / Litu | Body Width | 650mm |
| Travel Speed | 0-6km/h | Max. Operating Height | 3020mm |
| Hydraulic System | Gear Pump: Tianjin Xingzou / Multi-way Valve: Taiheng | Max. Pin Height | – |
| Max. Lifting Capacity | 830kg | Max. Dump Height | 1960mm |
| Max. Gradeability | 25% | Ground Clearance | 60mm |
| Fuel Tank Capacity | 25L | Bucket Dump Angle | 30° |
|
OPTION ● Standard 〇 Optional — N/A |
ENGINE |
1. Rato R740: Twin-cylinder Gasoline (EPA/EURO5), 16.8kw/3600r/min 2. Kubota D902: Three-cylinder Diesel (EPA/EURO5), 11.8KW/2300r/min 3. Kubota D1105: Three-cylinder Diesel (EPA/EURO5), 14KW/2200r/min 4. Yanmar 380: Three-cylinder Diesel (EPA/EURO5), 14.6KW/2500r/min 5. Xinchai 3B11: Three-cylinder Diesel (EURO5), 16.2KW/2200r/min 6. Laidong 385: Three-cylinder Diesel (EURO5), 18.4kw/2800r/min |
| 〇Rubber (width * pitch * number of sections) | – | |
| 〇Steel (width * pitch * number of sections) | – | |
| Tires | 6.5-10 | |
| Cab | Upgradable with Glass | |
| Canopy | ● | |
| Armrest | ● | |
| Tensioning Type | Mechanical Tensioning | |
| Air Conditioning (A/C) | 〇 |
