SDLGA-4
| Outside Dimension | 3250*1350*2050mm | Controller | 48V,60V、72V |
| Passengers Capacity | 4 | Battery Type | Lead acid battery、Lithium iron phosphate battery |
| Max.Speed | 40km/h &25mph | Charger | Intelligent high-frequency car charger |
| Max.Travelling Range | 80-100km | Charging Time | 6-8 hours |
| Slope Climbing Capacity | 30% | Braking System | Front/Rear Disc Brake,EMB system |
| Turning Radius | 4m | Front Axle and Suspension | Independence suspension |
| Ground Clearance | ≥125mm | Rear Axle and Suspension | Torsion beam |
| Brake Distance | ≤4m | Steering | “Rack &Pinion”Steering |
| Wheelbase | 2440mm | Display | LCD instrument,show time,speed,driving range,battery capacity,etc |
| Front/Rear Tread | 940/1030mm | Light | Front &rear combination LED lights |
| Weight | 600kg | Seat | Bus cold foam sponge +high-resilience PU leather fabric |
| Tire | 20*10-12,with aluminium alloy wheel rim | Body Material | Steel frame +ABS engineering plastic moldingmaterial |
| Motor | 4KW、5KW、7.5KW |
