SDLE35
| Overall weight | 1.85t | Overall Length | 3315mm |
| Engine Brand | CHANGCHAI 390 | Overall Width | 1400mm |
| Rated Power | 18.4kw | Overall Height | 2400mm |
| Digging Bucket Capacity | 0.03m³ | Track Width | 230mm |
| Bucket Width | 500mm | Track Length | 3888mm |
| Traveling Motor | RUILI / LIDUN | Body Width | 1150mm |
| Travel Speed | 0-1.8KM/h | Max. Digging Radius | 3660mm |
| Swing Motor | RUILI / LIDUN | Max Digging Depth | 2375mm |
| Swing Speed | 8r/min | Max. Digging Height | 2430mm |
| Hydraulic system |
Tianjin Xingzhou Precision Gear Pump Integrated Monoblock Valve: Taiheng |
Max. Unloading Height | 1570mm |
| Body Swing Radius | 894mm | Min. Swing Radius | 820mm |
| Body Swing Angel | 360 | Max. Digging Depth Of Dozer Blade | 160mm |
| Boom Swing Angel(L/R) | 45°-55° | Max. Lifting Height Of Dozer Blade | 170mm |
| Max. Grade Ability | 15° | ||
| Fuel tank | 21L | ||
| Hydraulic oil tank | 21L |
