SDLE25
| Overall weight | 1.5t | Overall Length | 3500mm |
| Engine Brand | Laidong 385 | Overall Width | 1200mm |
| Rated Power | 18.4kw | Overall Height | 2413mm |
| Digging Bucket Capacity | 0.03m³ | Track Width | 200mm |
| Bucket Width | 484mm | Track Length | 1400mm |
| Traveling Motor | RUILI / LIDUN | Body Width | 1000mm |
| Travel Speed | 0-1.8KM/h | Max. Digging Radius | 3668mm |
| Swing Motor | RUILI / LIDUN | Max Digging Depth | 2272mm |
| Swing Speed | 8r/min | Max. Digging Height | 3218mm |
| Hydraulic system |
Tianjin Xingzhou Precision Gear Pump Taiheng Integrated Monoblock Valve |
Max. Unloading Height | 2358mm |
| Body Swing Radius | 820mm | Min. Swing Radius | 770mm |
| Body Swing Angel | 360 | Max. Digging Depth Of Dozer Blade | 250mm |
| Boom Swing Angel(L/R) | 45°/45° | Max. Lifting Height Of Dozer Blade | 170mm |
| Max. Grade Ability | 15° | ||
| Fuel tank | 12L | ||
| Hydraulic oil tank | 18L |
Product Gallery
