SDLD30
| Payload Capacity | 3T | Chassis Width | 1550mm |
| Curb Weight | Approx. 1.4T | Engine Model | Briggs & Stratton EPA |
| Gearbox Model | Guli-21 | Number of Cylinders | Twin-cylinder (Air-cooled) |
| Gearbox Gears | – | Power Output | 23 HP |
| Overall Dimensions (LWH) | 3350*1600*1550 | Cooling Method | Water-cooled |
| Cargo Box Dimensions (LWH) | 2200*1600*560 | Climbing Angle | 35 Degrees |
| Track (Model/Size) | 350*90*56 | Gears | 6 Forward + 2 Reverse |
| Track Type/Material | Agricultural Rubber Track | Unloading Function | Hydraulic single-cylinder rear dump |
| Ground Contact Length | 1730mm | Starting Method | Electric Start |
| Max. Travel Speed | 10km/h | Lifting Height | Box bottom to ground within 2m |
| Min. Travel Speed | 3km/h | Lifting Capacity | Approx. 1.5T |
